Whisperdamp Noiseless Metal
|
![[Product Image]](images/MPM_Collage.jpg) |
NM (Noiseless
Metal) is a range of products for damping structure borne sound, consisting of
two metal facing sheets bonded by a viscoelastic core. The sound damping qualities of
the viscoelastic core are temperature dependant.
For this reason NM panels are
supplied with cores optimized for different temperature ranges, depending on the
applications in which they are to be used.
|
| The two metal facing sheets in NM panels are usually cold rolled steel,
(Often referred to as Noiseless Steel) but in principle any type of metal or
alloy can be used, as can surface-treated sheet of various kinds. The metal
facing sheets are ideally equal thickness, but a certain amount of asymmetry can
be tolerated with minimal loss of acoustic properties. |
| NM
serves a dual purpose. It damps the resonant modes of the structure borne sound
and it replaces the sheet material that would otherwise be used in the
construction of the component, without any increase in thickness or weight. The
acoustical
deadness of NM is often sufficient to replace the need for additional heavily
loaded polymer layers needed to screen the noise radiation |
Key Benefits
 | Replaces structural material and is therefore virtually zero weight added |
| Damping is designed into product |
| Increase in sound transmission loss often equal to addition of equal mass
of barrier material to mass of metal panel |
|
|
